Building Electric Guitars

You can contact the author at martin.koch@buildyourguitar.com

plus sign

Additional information sorted by page number:


49

Pythonista for iOS allows to run Python code on your iPhone.

import motion
import time
import console
x=0
countThis=True
console.set_font('Courier New',64)
console.clear()
print('Start')
try:
    motion.start_updates()
    while True:
        data = motion.get_magnetic_field()[2]
        if (data > 500) and countThis:
            console.clear()
            x=x+4
            print(x)
            countThis=False
        elif (data < 50):
            countThis = True
        time.sleep(.001)
finally:
motion.stop_updates()

omz-software.com/pythonista


58

Aluoxid is available from cnc-plus.de


62

Manufacturer: OTORO Design Inc., www.otoro.jp
Available in
JAPAN: OFF Corporation Inc., www.off.co.jp
GERMANY: Dieter Schmid Werkzeuge GmbH, finetools.com
or Dictum, dictum.com


63

Verleimzwinge RB 107: verleimzwinge.de


63

Veritas T-slot blade clamp: veritastools.com


67

vacuvin.com


68

smcpneumatics.com/ZU05S.html


69

roarockit.com


88

radiantools.com


109

My "Parrot" vise is a replica of the Versa Vise made by willburtversavise.com

kregtool.com


123

The Arduino UNO compatible printed circuit board (PCB) shown in the book was designed using the Fritzing software (fritzing.org).
You do not need to install Fritzing if you want the PCB.

Step 1: Download the stepperDriver.fzz Fritzing file from BuildYourGuitar.com

Step 2: Upload the Fritzing file and order the PCB from aisler.net. The costs as of 2020 are about 17 Euros for two boards plus worldwide shipping plus VAT if applicable.


124

/*
MICROCONTROLLER ASSISTED FRET SLOT CUTTING JIG
Accompanying software to the book
Building Electric Guitars by Martin Koch
Version 1.0, December 2016
Controller: Arduino UNO or compatible
*/

#include <Stepper.h>
Stepper stepperMotor(200, 2, 3, 4, 5);
#define Button 12
#define LED 13

float scaleLength = 25.50; //Always enter the scale length in inches!
boolean zeroFret = false; //Change "false" to "true" if a zero fret is used.

float distanceFromNut, X;
float travelPerStep = 0.005; //Use 0.00635 for a 0.5 in. x 0.25 in. threaded rod
boolean cutMode = false;
long startTime, buttonPressDuration;

void setup() {
  pinMode(Button, INPUT_PULLUP);
  pinMode(LED, OUTPUT);
  stepperMotor.setSpeed(60); //rpm
}

void loop() {

  if (!cutMode) {
    powerMotorOff();
    startTime = millis();
    while (!digitalRead(Button)); //if button is pressed wait for release
    buttonPressDuration = millis() - startTime;
    delay(10);
    if (buttonPressDuration > 5000) cutMode = true;
    else if (buttonPressDuration > 1000) while (digitalRead(Button)) stepperMotor.step(-1); //wait for button press to stop
    else if (buttonPressDuration > 10) while (digitalRead(Button)) stepperMotor.step(1); //wait for button press to stop
    digitalWrite(LED, HIGH);
    delay(250);
    digitalWrite(LED, LOW);
    delay(250);
  }

  if (cutMode)  {
    distanceFromNut = 0;
    for (int fretslot = 0; fretslot <= 99; fretslot++) {
      digitalWrite(LED, HIGH);
      powerMotorOff();
      while (digitalRead(Button)); //wait for button press
      digitalWrite(LED, LOW);
      X = ( scaleLength * 25.4 - distanceFromNut ) / 17.8171537451058;
      if (fretslot == 1 && !zeroFret) X = X + 0.3;
      distanceFromNut += X;
      stepperMotor.step(X / travelPerStep);
    }
  }

}

void powerMotorOff() {
  digitalWrite(2, LOW);
  digitalWrite(3, LOW);
  digitalWrite(4, LOW);
  digitalWrite(5, LOW);
}

133

Carlos Santana - "Oye Como Va", youtu.be/9QhchQD_w0M


304

Pauline top height map: PDF
